參照標準規范/Refer to standard specifications 《醫院門窗使用技術評價導則》（DB33/T 3363-2016） 《醫療衛生建筑設計標準》GB/T 50378-2014 《建筑外門窗氣密、水密、抗風壓性能分析及檢測方法》GB-T7106-2008 《醫院建筑設計規范》CJJ/T 127-2008 產品特點/Product Features 適用于 手術室 無塵車間 實驗室 整體結構/Overall composition 門體（配置雙層300*500*5鋼化玻璃） 導軌 防塵罩 下臥地槽/Door body (equipped with double-layer 300 * 500 * 5 tempered glass), guide rail, dust cover, and lower floor groove 門體結構/Product Structure 懸吊輪組 面板 主骨架 填充層（普通蜂窩 鋁蜂窩 聚氨酯）/Suspension wheel group panel main skeleton filling layer (ordinary honeycomb aluminum honeycomb polyurethane) 外飾板為1.0mm厚鍍鋅鋼板/304不銹鋼板，表面靜電噴涂，防銹、防塵、防潮耐腐蝕便于清潔 /The exterior panel is made of 1.0mm thick galvanized steel plate/304 stainless steel plate, with electrostatic spraying on the surface, which is rust proof, dustproof, moisture-proof, corrosion-resistant, and easy to clean 高強度鋁合金上懸掛軌道、靜音輪組、不銹鋼軌道防塵殼、窄距離下臥地槽方便輪椅及病床出入/High strength aluminum alloy suspension track, silent wheel group, stainless steel track dust cover, narrow distance lower lying trough for convenient wheelchair and hospital bed access 技術參數/Technical Parameter 開門速度/opening speed 300-700mm/s 關門速度/closing speed 150-500mm/s 門體厚度/thickness 50mm 開門角度/Opening angle 180° 整機功率/Whole machine power 75w-100w 電源/voltage AC170V-264V 50/60HZ 自動關閉時間/Automatic shutdown time 常開狀態：開/關? 常閉狀態：可設置區間0.5s-45.9s Normally open state: open/closed. Normally closed state: can be set between 0.5s and 45.9s 整門寬度（單扇）/Whole door width (single leaf) 1100mm-3000mm 高度（單扇） /height(single leaf) 1800mm-3500mm 開門方式/Door opening method 手動/電動、刷卡、遙控、密碼、面部識別、腳感/Manual/electric, card swiping, remote control, password, facial recognition, foot sensation 門體防夾/anti pinch 標配*1組紅外電子眼（可定制多點式電眼、安全光幕）/Standard configuration * 1 set of infrared electronic eyes (customizable multi-point eyes and safety light curtains) 顏色配置/Color selection 不銹鋼、藍、白、黃、紅、綠（可定制）/Stainless steel, blue, white, yellow, red, green (customizable)
